Why This Is Difficult
Snow design problems usually come from what was assumed about drift and about clearing, rather than from the ground snow load itself.
- Ground snow load governs the base case, but drift and sliding loads frequently exceed it in the geometry that produces the worst case
- Unbalanced loading across a row produces a torsional case that uniform loading never reveals
- Whether the array is cleared after snowfall changes the design load and adds a safety plan that has to be documented
- Modules are usually rated to a mechanical load limit around 5,400 pascals, which array geometry can exceed in drift configurations
- Low-tilt arrays shed snow poorly, so design tilt affects both yield and the load that accumulates
- Clearing equipment and personnel loads are live loads that must be defined, since they are often larger than the snow being removed
Engineering Requirements
These are the inputs a snow load design requires.
- Ground snow load for the site at the required return period, with the source and code edition stated
- Exposure and thermal factors as defined by the applicable code, rather than assumed from experience
- Array geometry: tilt, row pitch, module overhang and the presence of any obstruction or taller structure upwind
- Clearing policy in writing: whether snow will be removed, and if so by what method and at what frequency
- Module mechanical load rating and the clamping zone allowed by the module manufacturer
- Combination with wind where the code requires it, and with live loads from maintenance access
Selection guidance: decide the clearing policy before the structure is designed. It is a decision with structural, operational and safety consequences, and it is much cheaper to make on paper.
How We Solve It
- Snow load basis stated explicitly, including ground load, exposure and thermal factors, so the design is auditable
- Drift and sliding cases checked where geometry creates them, rather than only the uniform case
- Unbalanced load cases evaluated, since snow distribution across a row is rarely uniform after a real snowfall
- Clearing policy reflected in the design: the structure either carries the accumulated load or is designed for cleared conditions with a documented access and safety plan
- Module clamping zone verified against the manufacturer approved position for the design pressure, avoiding module damage at the interface
- Low-tilt configurations recognised for what they are, with both a yield and a snow load consequence
Beyond the Structure
- Design tilt options presented with both the yield and the snow load consequence, so the trade-off is visible rather than implicit
- Maintenance access detailed where clearing is planned, including walkway provision, tool loads and fall protection
